Pole Mounted Transformer
Rated Voltage: 10–35kV
Frequency: 60Hz
Rated Current: 1200–2000A
Rated Short-Time Breaking Current: 16/20/25kA
Rated Peak Withstand Current: 40/50/63kA
Introduction
ANSI 60Hz Single Three Phase Pole Mounted Oil Immersed Distribution Transformer
Pole Mounted Transformer is specially designed and manufactured in full compliance with ANSI C57.12 standards, perfectly matching North American and United States utility grid requirements.
This overhead distribution transformer adopts high-grade silicon steel core and high-conductivity copper windings, featuring low no-load loss, low noise, high efficiency and excellent thermal stability. The fully welded steel tank is coated with anti-corrosion and weather-resistant paint, adapting to extreme outdoor environments such as high temperature, heavy rain, snow and coastal salt fog.
Built with strong overload capability and reliable insulation performance, our pole mounted transformers are widely used in residential communities, rural power grids, municipal engineering, farmland power supply and remote area distribution projects across the United States.
We provide full customization on voltage level, capacity, mounting bracket and wiring configuration, with strict factory testing and complete certification support, delivering stable, durable and cost-effective power distribution solutions for American utility companies and electrical contractors.
