Prefabricated Substation
| Parameter Name | Parameter Value |
| Rated Voltage | 12kV, 380V/220V |
| Rated Capacity | 250kVA~2500kVA (Customizable) |
| Rated Current on High Voltage Side | ≤630A |
| Rated Current on Low Voltage Side | ≤6300A |
| Short-Circuit Impedance | 4%~6% (Customizable) |
| Protection Level | IP44 (Outdoor) |
| Overall Dimensions | Customizable |
| Applicable Ambient Temperature | -25℃~+40℃ |
Introduction
Outdoor Compact Prefabricated Distribution Substation ANSI 60Hz
Product Introduction:
Our outdoor compact prefabricated distribution substations are fully factory-assembled and tested, enabling fast on-site installation for North American applications. Built to ANSI standards at 60Hz, these integrated units combine medium-voltage switchgear, transformers, and low-voltage distribution equipment in a single enclosure. Ideal for urban communities, parks, and industrial parks, they deliver reliable power with minimal setup time. Custom OEM/ODM designs are available for voltage, capacity, and enclosure configurations.
